Home > Copper And Copper Alloys >

Cu-ETP Bronze Sheet Metal UNS 5 Ppm Copper And Copper Alloys For Interior Design

Product Categories
Wuxi Zhongxin Special Steel Co.，Ltd
Contact Now

Cu-ETP Bronze Sheet Metal UNS 5 Ppm Copper And Copper Alloys For Interior Design

Brand Name : XINZHENG

Model Number : copper sheet

Certification : SGS

Place of Origin : CHINA

MOQ : 50kg

Price : 3000-10000 USD / MT

Payment Terms : T/T , L/C , Etc

Supply Ability : 4000 Ton / Month

Delivery Time : 5-25 days

Packaging Details : SEAWORTHY STANDARD EXPORT PACKAGE

Material : T2, T3, TP1, TP2, TU1, TU2,H96, H80, H90, H70, H65, H68, H62, H59, HP59-1, HMn58-2, HSn62-1, HMn55-3-1, HMn57-3-1, HAl60-1-1,

Standard : ASTM, AISI, JIS, SUS, EN, DIN, BS, GB

Standard specification : JIS H3250-2006,ASTM B152M,GB/T2040-2008,ASTM B36,ASTM B194,ASTM B888,ASTM B19, ASTM B122,etc

Specifications : T 0.2-20mm x W1000mm x L 2000-3500mm T 1.0-5.0mm x W1000-1500mm x L 2000-3500mm T 0.5- 30mm x W1000-2500mm x L 3000-6000mm T 30- 80mm x W1000mm x L 2000mm or as you required

thickness : 0.2mm~200mm

Width : 10 mm~2500mm

Length : 10mm~12000mm,or as requried

Surface : mill,polished,bright,hair line,brush,checkered,mirror,brush,antique,sand blast,etching,etc

Shape : Flat sheet , coil , strip, rod ,tube,pipe,square,rectangle,bar

Temper : O-H112; T3-T8; T351-T851

Application : manufacturing pins,rivets,gasket,nuts,conduits,the barometer spring,screen,radiator parts, etc

Pakcage : Standard export seaworthy package or as required.

Contact Now

ASTM UNS C10100 99.99 Oxygen Free 5 ppm Copper Sheet

COPPER SHEET / COPPER PLATE / BRASS SHEET / BRONZE SHEET OVERVIW

Product Name Copper Sheet / copper plate / bronze sheet / Brass Sheet
Material Copper
Standard ASTM, AISI, JIS, DIN, GB, EN
Grade C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920,C10930,
C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300,C12500,C14200,
C14420,C14500,C14510,C14520,C14530,C17200,C19200,C21000,C23000,C26000,
C27000,C27400,C28000,C33000,C33200,C37000,C44300,C44400,C44500,C60800,
C63020,C65500,C68700,C70400, C70620,C71000,C71500,C71520,C71640,C72200
T1,T2,T3,TU1,TU0,TU2,TP1,TP2,TAg0.1,
Shape Flat plate
Temper O-H112; T3-T8; T351-T851
Size thickness 0.3mm~100mm; Width 50mm~2500mm; Length 1000mm~12000mm
Surface Mill finish, polished, anodizing, brushing, sand blasting, powder coating,etc
Payment terms T/T,L/C,western union, Paypal
Price terms CFR,FOB,CIF,Ex-work,CNF
Application 1) Further making utensil.
2) Solar reflective film
3) The appearance of the building
4) Interior decorating:ceilings,walls,etc.
5) Furniture cabinets
6) Elevator decoraction
7) Signs,nameplate,bags making.
8) Decorated inside and outside the car
9) Household appliances:refrigerators,microwave ovens,audio equipment,etc.
10) The consumer electronics:mobile phones,digital cameras,MP3,U disk,etc.
Package Standard export seaworthy package or as required.
Copper sheet synonyms Copper OFC, Oxygen-free Copper, Copper OFHC, Oxygen-free high thermal conductivity copper, Copper OFE, Oxygen free electrolytic copper, Oxygen Free Electronic Copper, ASTM F68, Copper Alloy 101, C101, C102, C10100, C10200 Copper O, High-conductivity copper, C-110, C11000, C110 Electrolytic Tough Pitch (ETP) copper, Cu-ETP, C122, C-122, C145, C-145, C147, C-147, O60 (soft / annealed) temper, H00 (cold rolled), H01 (cold rolled, high yield), H02 (half hard) temper, H03 (three quarter hard) temper, H04 (full hard) temper

COPPER SHEET / COPPER PLATE Specification and Size

Copper sheet / copper plate / Bronze sheet / Brass sheet / Individual sheets made of copper –

Technique : Cold-rolled
Width
in mm		 Thickness in mm
3 – 4,8 > 4,8 – 6,5 > 6,5 – 8 > 8 – 10 > 10 – 12 > 12 – 35
30 – 670 max. 4000 mm long max. 4000 mm long max. 3100 mm long max. 3100 mm long max. 2500 mm long max. 6200 mm long
> 670 – 1000 max. 4000 mm long max. 4000 mm long max. 3100 mm long max. 3100 mm long max. 2500 mm long
> 1000 – 1250 max. 4000 mm long max. 3000 mm long max. 3100 mm long * *
> 1250 – 2030 max. 4000 mm long max. 3000 mm long

* Other dimension and specicificaiton is also available on request.

Copper plate / Bronze plate / Brass Plates made of copper

Technique : Hot-rolled
Width
in mm		 Thickness in mm
3 – 5 > 45 – 12 > 12 – 20 > 20 – 60 > 60 – 200 > 200
30 – 1000 max. 6000 mm long max. 8000 mm long max. 4000 mm long max. 6200 mm long max. 4000 mm * long
> 1000 – 2500 max. 6000 mm long max. 8000 mm long max. 4000 mm long max. 6200 mm long * *
> 2500 – 3000 * max. 4000 mm long max. 4000 mm long
> 3000 – 3200 * max. 4000 mm long
> 3200 * *
Cu-ETP Bronze Sheet Metal UNS 5 Ppm Copper And Copper Alloys For Interior Design* on request, Thickness up to 200 MM, width up to 3500mm ,Length up to 18 Metres
Cu-ETP Bronze Sheet Metal UNS 5 Ppm Copper And Copper Alloys For Interior Design

Cu materials/alloys
European standard DIN standard (former) ASTM Typical properties/application Manufacturing standard
Cu-ETP CW004A E-Cu 58 2.0065 C11000 standard alloy for electrical components, main appli- DIN EN 13599
E-Cu 57 2.0060 cation in switchgear construction DIN EN 1652
Cu-HCP Cu-PHC CW021A CW020A SE-Cu 2.0070 C10300 hydrogen-resistant, very high conductivity, easy to weld DIN EN 13599
Cu-OF CW008A OF-Cu 2.0040 C10200 hydrogen-resistant, very high conductivity, very easy to weld DIN EN 13599
Cu-OFE CW009A C10100 high purity, Cu 99.99% fur vacuum switching systems, targets DIN EN 13604
Cu-DHP CW024A SF-Cu 2.0090 C12200 very easy to weld, without particular conductivity requirements DIN EN 1652
DIN EN 1653 AD-2000W6/2
CuAg0,10P CW016A CuAg0,1P 2.1191 C10700 mould plates, commutator rings, electrodes DIN EN 13599
CuCrZr CW106 CuCrZr 2.1293 C18150 mould plates, welding equipment, furnace and mould engineering, heavy current engineering DIN 17670
CuNi2Si CW111C CuNi2Si 2.0855 C18000 mould engineering, machine parts, die casting equipment by arrangement

Products can be supplied by arrangement in compliance with other international standards such as BS, JIS and GOST.

Package and Transportation

Cu-ETP Bronze Sheet Metal UNS 5 Ppm Copper And Copper Alloys For Interior DesignCu-ETP Bronze Sheet Metal UNS 5 Ppm Copper And Copper Alloys For Interior Design
